Hydraulic Portable Automated Car Parking System

Brand Name : SDLIFT Or OEM

Model Number : SJG6-3

Certification : CE ISO SGS

Place of Origin : China

MOQ : 1 UNIT

Price : USD7800- USD13800 / UNIT

Payment Terms : T/T

Supply Ability : 1200units per year

Delivery Time : 30 days

Packaging Details : Iron case or plywood case package

Usage : Double Deck Car Parking System For Garage

Load capacity : 3000kg / 3000kg

Lifting Speed : 3m/min.

Safety Device : Explosion Proof Lock Valve

Certificate : CE / ISO

Drive mode : hydraulic

Contact Now

Hydraulic Portable Car Lift Double Deck Car Parking System with CE

1) Load capacity: 3000kgs (lower platform)
3000kgs (upper platform)
2) Platform size: 5.6m x 2.8m (lower platform)
5.6m x 2.8m (upper platform)
3) Lift height: 3m
4) Height between platforms: 3m
5) Power: 380v/50hz/3ph/5.5kw
6) Control system: 1 control box, 1 control panel
7) Control buttons: up, down, stop, emergency
8) Safety device: explosion-proof lock valve
9) Standard: CE, ISO9001

Product Description

The Hydraulic Portable Car Lift Double Deck Car Parking System can be used to lift cars with different levels, suitable for car moving between stairs, from basement to first floor, or to second floor. Steady working and easy operation, it can be installed underground or in basement ---Invisible Parking Solution for Private House!

Model list

Model load capacity Platform size Lift height Pit depth Power
SJG2.5-3 2.5T 5.2m×2.6m 3m 750mm 220v, 240v,380v or 400v
SJG2-6.5 2T 5.2m×2.8m 6.5m 800mm 220v, 240v,380v or 400v
SJG2.5-3.5 2.5T 5.2m×2.6m 3.5m 800mm 220v, 240v,380v or 400v
SJG2.5-5 2.5T 5.6m×3m 5m 800mm 220v, 240v,380v or 400v
SJG3-2.5 3T 5m×2.3m 2.5m 750mm 220v, 240v,380v or 400v
SJG3-3 3T 5.2m×2.6m 3m 800mm 220v, 240v,380v or 400v
SJG3-3.5 3T 5.6m×2.7m 3.5m 800mm 220v, 240v,380v or 400v
SJG5-10 5T 4.5m×2.5m 10m 1150mm 220v, 240v,380v or 400v
SJG8-2.5 8T 6.5m×4.5m 2.5m 850mm 220v, 240v,380v or 400v
SJG12-3 12T 5.5m×2.8m 3m 950mm 220v, 240v,380v or 400v
SJG15-4.5 15T 8m×2.2m 4.5m 1150mm 220v, 240v,380v or 400v
SJG20-5 20T 6m×3m 5m 1200mm 220v, 240v,380v or 400v

Advantages

1) Explosion-proof lock valve to avoid a sudden drop if emergency occurs.

2) The limit switch system helps Double Parking Car Lift to stop at accurate position.

3) Electricity leakage protection device is equipped on, all electric components are CE certified.

4) All the Double Parking Car Lift are passed 1.2 times loading test before leaving factory.

Detailed Images

Hydraulic Portable Automated Car Parking System

Production pictures:

​Hydraulic Portable Automated Car Parking System

Hydraulic Portable Automated Car Parking System

Hydraulic Portable Automated Car Parking System

Package and loading into a container:

Hydraulic Portable Automated Car Parking System

Hydraulic Portable Automated Car Parking System


CE Certificate:

Hydraulic Portable Automated Car Parking System

Our service:

1) We can design the customerized Double Deck Car Parking System as per your requirement.
2) The Double Parking Car Lift will be recommended to you once we got your requirement.
3) Shipment can be arranged from our port to your destination port.
4) Operation video can be sent to you if needed.
5) User-friendly English manual for machine installation using and maintenance.
6) 2 year warranty for whole machine without man-made faults.
7) We will send you parts for free if any non-human factors faults during warranty time.
8) Supply 24-hours technical assistance by email, telephone or other communication online.
9) Engineers are available to your country if necessary.
